H3C R4950 G5

CPU

1 or 2 x AMD EYPC TM 7002/7003 series Processor

Memory

16 or 32 DDR4/3200MHz/ECC/REG solts,Up to 4TB

Disk

24x2.5 or 12x3.5 inch SAS/SATA/SSD drives

Raid card

1 x SAS 12Gb/half height/PCIe 3.0 x8/2GB cache/support RAID 0,1,5,6,10,50,60.
Standard PCIe HBA or RAID controller (SATA RAID 0, 1, 5, and 10), depending on model.

Network

2 x OCP 3.0 slots for 4 x 1GE or 2 x 10GE or 2 x 25GE NICs
PCIe Standard slots for 1/10/25GE/IB Ethernet adapter

Power supply

Up to 2 x Platinum 550W/800W/850W/1200/1600W/2000W (1+1 redundancy)

1

Optional 12LFF hard drive

2

USB 3.0 interface

3

Optional hard disk or LCD touchable intelligent management module

4

Pull-out asset tag

5

Dedicated management interface

6

USB 2.0 interface

7

VGA interface

1

Bay 1, optional 8SFF hard drive

2

Bay 2, optional 8SFF hard drive

3

Bay3, optional 8SFF hard drive

4

USB 3.0 interface

5

Optional hard disk or LCD touchable intelligent management module

6

Pull-out asset tag

7

Dedicated management interface

8

USB 2.0 interface

9

VGA interface

1

Optional 25SFF hard drive

2

USB 3.0 interface

3

Optional hard disk or LCD touchable intelligent management module

4

Pull-out asset tag

5

Dedicated management interface

6

USB 2.0 interface

7

VGA interface

1

PCIe slot 1~slot 3

2

PCIe slot 4~slot 6

3

Optional PCIe slot 7~slot 8

4

Power Module 2

5

Power Module 1

6

USB 3.0 interface(2)

7

VGA interface

8

serial port

9

HDM dedicated network interface (1Gb/s, RJ45, default IP address: 192.168.1.2/24)

10

Optional OCP 3.0 network card

Product Description

Original H3C UniServer R4950 G3 SFF for h3c server

Type

Server-rack-mountable

Height (Rack Units)

2U Dual Socket Rack Server

Server Scalability

4-way

Processor

4CPU

RAM

64GB

Storage Controller

SATA (SATA 6Gb/s)

Dimensions (WxDxH)

60cm x 40cm x 15cm

Weight

15kg

Pricing Type

CTO

Manufacturer Warranty

3years

Storage Controllers

RAID controller and SAS controller
The onboard PCH supports 14*SATA ports
Intel onboard NVME controller,The Intel NVME Raid Key is optional

RAM Supported

2 hot-swappable/redundant:

550W/750W/1100W/1600W 80 PLUS platinum power supply;

750W 80 PLUS titanium power supply;

-48V DC 80 PLUS platinum power supply.

Bays

Supports hot-swappable hard drives:
Up to 14 3.5-inch hard drives;
Or up to 24 2.5-inch hard drives (up to 12 AnyBays, or up to 24 Nvmes) + 2 3.5-inch rear hard drives;
Two M.2 boot disks connected to the PCH through PCIe ports (RAID1 supported)

Slots

12 (total) / 11 (free) x DIMM 240-pin 2 (total) / 1 (free) x CPU 1 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height (x4 mode) 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height (x8 mode) 1 (total) / 1 (free) x PCIe 2.0 x8 - low-profile (x4 mode) 1 (total) / 1 (free) x SD card
